Design standards
Design and manufacture as GB/T 12235、DIN 3356
Face to face dimensions asGB/T 12221、DIN 3202
End flange dimension as JB/T 79、DIN 2543
Pressure test as GB/T 26480、DIN 3230
Performance Specification
Nominal pressure:1.6,2.5,4.0,6.3MPa
Strength test:2.4,3.8,6.0,9.5MPa
Seal tese:1.8，2.8，4.4，7.0MPa
Gas seal test:0.6MPa
Valve body material:WCB(C),CF8(P),CF3(PL),CF8M(R),CF3M(RL)
Suitable medium:water,steam,oil,products,nitric
Suitable temperature:-29°C~425°C
Product Structure
The American standard 、 Japanese standard globe valve of Anix is simple in structure and easily manufactured and maintained. The valve has small working stroke, short opening and closing time, good sealing performance, small friction on the sealing faces and long service life, suitable to be used for cutting off, regulating or throttling the media. The valve has relatively short opening or closing stroke of the valve rod and very reliable cutoff action. The valve seat and the flap are easy to be repaired; during replacement of the sealing components, there is no need to dismantle the whole valve from the pipes.
globe valve of Anix is simple in structure and easily manufactured and maintained. The valve has small working stroke, short opening and closing time, good sealing performance, small friction on the sealing faces and long service life, suitable to be used for cutting off, regulating or throttling the media. The valve has relatively short opening or closing stroke of the valve rod and very reliable cutoff action. The valve seat and the flap are easy to be repaired; during replacement of the sealing components, there is no need to dismantle the whole valve from the pipes.
The German standard and national standardgate valves of Anix have reliable sealing, good performance and elegant appearance, in accordance with advanced national and international standards. The gate plates and the valve seats are wearing, high temperature and corrosion resistant, and have good scratch resistant performance and long service life. Wedge type elastic gate plate structure is used; roller bearings are provided for medium and large diameters to realize easy opening and closing; the valve rods are subject to tempering and surface nitrogen treatment and thus have good corrosion resistant and scratch resistant performance. Different pipe flange standards and flange sealing face types can be used to meet the requirements of different projects and users. There are a complete range of materials to be used for the valve bodies, and the packing and gaskets can be selected according to the actual working conditions or the requirements of the users. The valves are thus applicable to different working conditions with various pressure, temperature and media.
