American standard flange ball valve

American standard flange ball valve

The American standard flange ball valve of Anix is manufactured on the basis of many years’ experience in development and manufacture of ball valves :
1. the valve seat is designed to be of double lip seal structure to enhance sealing and reduce the operation torque; the valve seat can be made of various materials, suitable for more areas;
2. the valve rod is designed to be of explosion proof structure and bottom mounting type to prevent flying out under pressure; PTFE guide is also used to reduce friction on the valve rod and reduce the operation torque;
3. the valve is designed to be of fireproof and anti-static structure; it can also be customized according to the requirements of the clients or the working conditions.
Online Inquiry Contact Us

Product Description

Design standards
Technical code: American standard
Design standard: API6D API608
Structural length: ASME B16.10
Connecting flange: ASME B16.5
Test and inspection: API6D API598
Performance Specification
Nominal pressure: 150, 300, 600LB
Strength test: 3.0, 7.5, 15Mpa
Seal test: 2.2, 5.5, 11Mpa
Back seal test: 2.2, 5.5, 11Mpa
Gas seal test: 0.6Mpa
Valve body material: WCB(C), CF8(P), CF3(PL), CF8M(R), CF3M(RL)
Applicable media: water, oil, gas, chemical industry, power stations, etc.
Applicable temperature: -29℃ to 180℃

Product Structure
